Boafeng UV25

Specifications of Baofeng UV-25 Portable Radio (10 Watt)

(Updated Version of the Baofeng AR-152)

High Power & Enhanced Signal

Equipped Tri-Power settings ( high/ medium/low) ,ensuring robust signals, enhanced obstacle penetration, and extended reach for both transmission and reception distances.

Broad Frequency Range

It supports UV dual band transmission and a multitude of reception frequency bands including 136-174MHz, 400-520MHz, 65-108MHz, 108-136MHz, 200-260MHz, 350-390MHz, and NOAA weather channels, and storage capacity of up to 999 channels. This feature guarantees communication across various bands and access to important weather updates.

Long-Lasting Battery Life

Equipped with a 2800mAH high-capacity battery and a Type-C charging port, it ensures extended operational times and convenient emergency charging with flexible power on the go.

User-Friendly Design

The device has large buttons and a friction-enhanced power-on knob for easy blind operation. Its metal construction makes it sturdy and resistant to falls and impacts, and it is equipped with a top flashlight that can serve as an SOS signal during emergencies, adding/deleting a memory channel,adding/removing a channel from the scanning list, adjusting VOX/squelch/power save levels. Support Chirp quick programming.

One Touch Frequency Search / Wireless Copy Frequency

Use the [SK1] key to clone frequencies between devices, streamlining communication processes, making it more convenient and efficient. This feature enables efficient setup and frequency management, making it user-friendly for both beginners and experienced users.

Type-C Fast ChargeR

Type-C charging is a trend for mobile devices as it has low requirements for power sources and places. The UV-25 is Type-C USB rechargeable, for which you can easily charge it like a phone in your car, with a power bank or laptop. Portable for your go-kit.

SMA-Female JacK

Compatible with SMA-Female antenna （ recommend our folded tactical antenna: Sold Separately)

K-port

Compatible with K-port (2 Pin) headset, speaker mic, programming cable.

• Frequency range:
  Multi Band
  AM: 108-136MHz (Rx ）
  VHF: 136-174MHz (Rx/Tx)
  VHF: 200-260MHz (Rx/Tx)
  UHF: 400-520MHz (Rx/Tx)
  UHF: 350-390MHz (Rx ）
  FM: 65-108MHz (Rx)

Tri Band
136-174 / 220-260 / 400-520MHz

• Channel Spacing: 25.0 KHz (Wide)/12.5 KHz (Narrow)
• Memory Channel: 999 Groups
• Operation Voltage: DC 7.4 V ±10%
• Transmission Current: ≤2800 mA
• Receive Sensitivity: 0.25 μV (12dB SINAD)
• Rated Audio Power Output: 1W @16 ohms
• Receive Current: ≤380 mA
• Connection for Accessories: 2-pin Kenwood jack
• Antenna Impedance: 50 Ohm
• Dimensions: 7.1 x 2.7 x 1.8'' / 180 x 70 x 45mm
• Weight: 0.59kg / 1.3lb

Feature and Functions of Baofeng UV-25 Walkie Talkie

• Dual watch, dual reception, and dual-band capabilities
• Manageable power-on password protection
• Scramble functions
• Channel scan, frequency scan, and three scan and recovery methods: TO, CO, and SE
• Stopwatch and alarm function
• Programmable display illumination via keypad
• Programmable repeater offset
• Selectable high/medium/low power modes
• Function beep on the keyboard
• Battery save mode
• Transmission time-out timer(TOT)
• Busy channel lockout and programmable repeater offset
• LED flashlight
• Ten levels of squelch (SQL) adjustment

Gooseneck Antenna

• Antenna Gain: 2.5 dBi
• Antenna SWR: ＜ 1.5
• Frequency: 136~174/400~520 MHz
• Antenna Connector Type: SMA-Female
• Max Power: 20 Watts
• Length: 13.3’’ / 33.8cm

**Radios Only Available to Lisenced Radio Amateurs with local ICASA licence**

It is illegal to transmit with this radio without an Icaasa License
